The compact and exquisite structural design. (It can effectively save equipment space. The micro-miniature design of the equipment is realized)
360° shielding provides all-round EMC protection (anti-electromagnetic interference). Multi-core type 2 - 32 cores, high-density installation saves space.
Automotive & Motorsport– Engine compartment sensors, transmission controls, exhaust gas monitoring, and battery management systems.
Aerospace & Avionics– Engine nacelle sensors, bleed air systems, and propulsion control interfaces.
Industrial Processing– Furnace temperature probes, kiln sensors, and glass manufacturing equipment.
Semiconductor Manufacturing– Wafer processing chamber interconnects and bake-out oven connections.
Navigation GPS, satellites, radar
| Parameter | Specification |
| Insulator Material | PPS |
| Shell Material | Brass with nickel plating (standard); |
| Shell Sizes | 0, 1, 2, 3 |
| Contact | 2 to 32 pins |
| Contact Material | Copper alloy with gold plating |
| Operating Temperature | -45°C ~ +125°C |
| Mating Cycles | >5,000 operations |
| Ingress Protection | IP68 |
| Salt Spray Resistance | >72 hours |
| Insulation Resistance | ≥5000MΩ |
| EMI Shielding | All-metal housing provides 360° shielding |
| Termination Styles | Solder and PCB mount |
All T Series connectors are RoHS-compliant and undergo 100% electrical testing—continuity, insulation resistance, and dielectric withstand—before shipment.
| Aspect | Reunion T Series | Typical European/US High-Temp Series |
| Insulator Material | PPS or PEEK | PEEK often offered as expensive option |
| Price | Approximately 1/3 of premium brand pricing | Premium cost for high-temp capability |
| Availability | Standard product line with short lead times | Often custom-order with longer lead times |
| MOQ | No MOQ for standard configurations | High MOQ for high-temp variants |
| Customization | Fast engineering response for custom pin/load | Slow, rigid for high-temp designs |
| Factory Experience | 15 years in-house with dedicated high-temp production line | Often outsourced to specialty suppliers |
Reunion provides comprehensive customization for the T Series to meet specific thermal and mechanical requirements.
Shell Plating–Chrome (standard), black chrome
Insulator Material– PPS (standard) or PEEK (custom)
Contact Plating– Gold (Optional gold plating thickness)
Contact Loading– Populate only required contacts; dummy pins for mechanical balance.
Cable Assemblies– Customized production according to application requirements
CNC Machining – High-speed automatic lathes produce shells with ±0.02mm tolerance.
Plating – Shell plating and contact selective gold plating in automated lines with bath concentration monitoring.
Injection Molding – Insulators molded from engineering plastics.
Assembly – Semi-automated lines with vision inspection for contact alignment and insertion force.
Testing – 100% electrical verification (continuity, insulation, dielectric strength) with data logging for each batch.
Packaging – Anti-static vacuum bags with desiccant; bulk packaging for high-volume automated assembly lines.
Samples usually 10~12 days.
Order usually 15~20days.
Special cable specification customization: 20~30days
We recommend specifying your cable type, length, connector configuration, and any heat-shrink requirements at the quotation stage—our engineering team will then provide a firm delivery commitment within 48 hours. Stock standard configurations are always available with no MOQ.
