250V/20A current capacity, suitable for most LED displays on the market. Made of PA6+25GF, Fire rating UL94-V0,corrosion-resistant, with excellent electrical properties and good electrical insulation performance.
Every production batch of the Reunion H series power connector undergoes 100% electrical verification (contact resistance ≤5mΩ; insulation ≥1000MΩ) before packaging.
| Critical Parameter | H Series Performance |
| Cores | 3-core |
| Power | 250V/20A |
| Contact type | Solder, PCB |
| Mating cycle | 》1,000 times |
| Temp Range | -45°C to +125°C |
| Environmental Seal | IP50 standard |
| Safety Approvals | UL Recognized, CB, CQC, and fully RoHS/REACH compliant |
Vertical Integration:Precision machining, selective gold plating, and automated assembly occur under one roof—eliminating subcontractor variability.
Certified Management: ISO 9001 (Quality), 14001 (Environment), and critically ISO 13485:2016 for medical-device production, ensuring rigorous document control and risk management.
Rapid Response: A dedicated 8-person FAE team provides 24-hour technical support for custom recommendations. Minimum order quantity (MOQ) for cable assembly at just 100 pieces—significantly lower than European premium brands.
Cable Assemblies – Custom length (0.2m to 20m), Specification requirements.
Connector – Straight or right-angle; panel-mount or cable-mount versions.
Termination Style – Solder, PCB, or flying-lead (stripped and tinned wires).
Cable Marking – Custom printing or heat-shrink labels for circuit identification.
Color - Housing color, cable color or overmolding color
Packaging – Bags, reels, or custom-labeled cartons.
